창고 스토리지 솔루션
스토리지 랙
엑소텍의 랙은 귀사의 창고에서 사용 가능한 총 저장 공간을 최대화하도록 설계되었습니다.
모듈형 설계를 통해 다양한 창고 크기에 맞게 랙을 구성할 수 있습니다. 최대 높이 12미터(39피트)에서 사용될 경우, 랙은 자동화되지 않은 스토리지(보관) 솔루션보다 최대 5배 더 많은 스토리지 밀도를 제공합니다.
저장용 용기(Bin)
랙의 모듈식 설계는 빠른 설치 및 가동 준비를 가능하게 합니다. 기존 자동화에 소요되는 시간이나 기존 스카이 포드® 시스템의 확장 일정에 비추어 볼 때 빠른 설치 및 가동 준비야말로 상당한 이점입니다. 실제로 작업 중단을 최소화하면서 시스템에 랙을 추가할 수 있습니다.
또한 당사의 랙은 FM 글로벌 자동 스프링클러 규정을 준수합니다.
엑소텍의 저장용 용기(Bin)는 다양한 SKU를 보관할 수 있도록 제작되었습니다. 다양한 높이로 제공되는 재활용 플라스틱 용기는 여러 칸으로 나누어 저장 밀도를 더욱 향상시킵니다.
품목의 크기에 따라 용기는 세 가지 높이로 제공됩니다.
- 220mm
- 320mm
- 420mm
분리 가능한 플라스틱 칸막이를 사용하여 용기를 2, 3, 4, 6 또는 8개의 칸으로 나눌 수 있습니다.
칸으로 용기를 나눌 때 일반적으로 함께 주문되는 물품을 동일한 상자에 배치하여 전반적인 효율성을 높일 수 있습니다.
트레이
기존 인프라를 극대화하기 위해 당사에서는 다양한 기존 상자 크기와 주문처리 컨테이너를 지원하는 트레이를 개발했습니다.
이러한 트레이를 사용하면 Exotec® 용기에 아이템을 옮겨 담을 필요가 없으며 이들 트레이는 최대 600 x 400 x 400mm 크기의 상자에 적합합니다.
Frequently Asked Questions
What is the maximum height of the racks?
Our racks can reach up to 39 feet (12 meters) with a required clearance of only 0.5 meters between the top of our racks and the ceiling. This design allows for the utilization of the entire vertical space in the vast majority of warehouses throughout North America. The adaptability of our rack heights ensures that they can be tailored to fit a wide range of warehouse configurations, thereby maximizing the efficiency and effectiveness of your warehouse storage solutions.
How much can each storage bin hold, in regard to weight and size?
The Skypod system storage bins are designed to accommodate a wide range of products, making them suitable for diverse industries such as retail, healthcare, industrials, and grocery. Our bins are available in three heights and offer flexible partitioning options to cater to different product sizes. If the item fits into our bins or case fits onto our trays, our system is fully equipped to handle it.
- Bins: Our bins are 450 x 650 mm (17.5 x 25.5 in). They are available in three different heights – 220, 320, and 420 mm (8.6 x 12.6 x 16.5 in). For increased storage density, these bins can be partitioned into 2, 3, 4, 6, or 8 compartments using removable dividers.
- Trays: Our trays facilitate the quick and automated entry and removal of cartons from storage, eliminating the necessity for decanting. These trays are suitable for carton sizes up to 600 x 400 x 400 mm (23.5 x 15.5 x 15.5 in).
Additionally, our trays facilitate the quick and automated entry and removal of cartons from storage, eliminating the necessity for decanting. These trays are suitable for carton sizes up to 600 x 400 x 400 mm (23.5 x 15.5 x 15.5 in). Full and mixed case picking is enabled from our trays.
Is it possible to have bins and trays within the same system?
Yes, this unique capability within the Skypod system accommodates a wide array of order profiles, enables omnichannel order fulfillment, and maximizes the efficiency of order fulfillment processes.
Do I need to remove any existing pillars in my warehouse to install Exotec racks?
No. The installation of Exotec racks is designed to be minimally invasive to your existing warehouse structure. There is no need to remove existing pillars, as the system can be configured around them.
How are bins and trays inducted into the system?
New bins/trays are seamlessly added to the system through a dedicated mode at the station.
How does Exotec streamline the process of adding racks to an existing system?
Expanding the storage capacity of an existing Exotec system is a streamlined and efficient process. The procedure involves:
- Assessment: Initially, we conduct a thorough assessment of your warehouse’s current setup and operational needs to determine the most effective approach for expansion.
- Decoupled Expansion: A key aspect of our system is the decoupling of throughput from storage. This means you can expand storage capacity without necessarily having to increase throughput capabilities, allowing for more cost-effective and need-based capital expenditures.
- Quick Implementation: Adding storage racks to your existing system can be completed in just a few weeks. Our focus is on ensuring that the additional storage integrates seamlessly with your current setup, enhancing your warehouse storage solutions’ overall functionality and efficiency.
This approach ensures rapid expansion of storage capacity and aligns the expansion with your specific operational requirements and budget considerations.
